Mini-Project | Sem 3¶

Cyber Security - CyberAttacks¶

Aadith Sukumar | AIML A1 | 21070126003¶

Cyber operations dataset

Cyberwar CyberAttack

Contents¶

  1. Cover
  2. Contents
  3. Importing libraries
  4. Loading Dataset
  5. Learning about dataset
  6. Visualization
    • Categories of cyber attacks
    • Types of cyber attacks
    • Major sponsors of cyber attacks)
  7. Russian cyber attack on Ukraine
  8. Web-Scraping
  9. Applying NLP

Importing required libraries¶

In [1]:
import pandas as pd
import numpy as np
import matplotlib.pyplot as plt
import seaborn as sns
import missingno as mn
import zipfile
import plotly
import plotly.graph_objs as go
import plotly.express as px
from plotly.subplots import make_subplots
from bs4 import BeautifulSoup
import requests
from nltk.tokenize import word_tokenize
from nltk.corpus import stopwords
import warnings
warnings.filterwarnings('ignore')

Loading dataset¶

In [2]:
!kaggle datasets download -d "fireballbyedimyrnmom/cyber-incidents-up-to-2020"

cyber-incidents-up-to-2020.zip: Skipping, found more recently modified local copy (use --force to force download)
In [3]:
# Unzipping the dataset downloaded
zipfile.ZipFile('cyber-incidents-up-to-2020.zip').extractall()

cyber=pd.read_csv('./cyber-operations-incidents.csv')

cyber.head()
Out[3]:
Title Date Affiliations Description Response Victims Sponsor Type Category Sources_1 Sources_2 Sources_3
0 Attack on Austrian foreign ministry 2/13/2020 Turla The suspected Russian hackers conducted a week... Confirmation https://www.theregister.co.uk/2... Austrian Foreign Ministry Russian Federation Espionage Government https://www.theregister.co.uk/2020/02/14/austr... https://www.bmeia.gv.at/en/the-ministry/press/... NaN
1 Spear-phishing campaign against unnamed U.S. g... 1/23/2020 Konni Group The suspected North Korean threat actor Konni ... NaN Employees of the U.S. government Korea (Democratic People's Republic of) Espionage Government https://unit42.paloaltonetworks.com/the-fractu... NaN NaN
2 Australian Signals Directorate 4/6/2020 NaN Responsible for attacking infrastructure that ... NaN NaN Australia Data destruction Private sector https://www.minister.defence.gov.au/minister/l... https://www.zdnet.com/article/australia-on-the... NaN
3 Catfishing of Israeli soldiers 2/16/2020 APT-C-23 The Hamas-associated threat actor APT-C-23 tar... Hack Back https://www.bleepingcomputer.com/n... Israeli Defense Forces (IDF) soldiers Palestine, State of Espionage Military https://www.bleepingcomputer.com/news/security... https://research.checkpoint.com/2020/hamas-and... NaN
4 Targeting of U.S. companies and government age... 8/10/2020 Fox Kitten Iranian hackers attacked high-end networking e... NaN U.S. government agencies, U.S. companies Iran (Islamic Republic of) Espionage Government, Private sector https://www.cybersafe.news/fbi-warns-about-ira... https://www.zdnet.com/article/fbi-says-an-iran... NaN

Learning more about the dataset¶

In [4]:
cyber.info()

<class 'pandas.core.frame.DataFrame'>
RangeIndex: 481 entries, 0 to 480
Data columns (total 12 columns):
 #   Column        Non-Null Count  Dtype
---  ------        --------------  -----
 0   Title         481 non-null    object
 1   Date          474 non-null    object
 2   Affiliations  347 non-null    object
 3   Description   481 non-null    object
 4   Response      86 non-null     object
 5   Victims       453 non-null    object
 6   Sponsor       439 non-null    object
 7   Type          447 non-null    object
 8   Category      458 non-null    object
 9   Sources_1     475 non-null    object
 10  Sources_2     355 non-null    object
 11  Sources_3     168 non-null    object
dtypes: object(12)
memory usage: 45.2+ KB
In [5]:
cyber.describe(include='all')
Out[5]:
Title Date Affiliations Description Response Victims Sponsor Type Category Sources_1 Sources_2 Sources_3
count 481 474 347 481 86 453 439 447 458 475 355 168
unique 477 403 262 479 80 387 39 7 24 450 343 164
top Targeting of Ukrainian government entities 10/4/2018 Believed to be the work of APT 28 Gamaredon, a Russian-speaking APT, targeted Uk... Criminal charges https://www.justice.gov/opa... United States China Espionage Private sector https://blogs.microsoft.com/on-the-issues/2020... https://blog.malwarebytes.com/threat-analysis/... https://www.washingtonpost.com/world/national-...
freq 4 6 15 3 2 21 167 374 128 4 2 2
In [6]:
cyber.columns
Out[6]:
Index(['Title', 'Date', 'Affiliations', 'Description', 'Response', 'Victims',
       'Sponsor', 'Type', 'Category', 'Sources_1', 'Sources_2', 'Sources_3'],
      dtype='object')
In [7]:
print("Size =",cyber.size)
print("Shape =",cyber.shape)

Size = 5772
Shape = (481, 12)

Finding NULL Values in DataSet¶

In [8]:
# NULL values 'count' across columns
cyber.isnull().sum()
Out[8]:
Title             0
Date              7
Affiliations    134
Description       0
Response        395
Victims          28
Sponsor          42
Type             34
Category         23
Sources_1         6
Sources_2       126
Sources_3       313
dtype: int64
In [9]:
# NULL values 'percentage' across columns
round(cyber.isnull().sum() / cyber.shape[0] * 100.00, 2)
Out[9]:
Title            0.00
Date             1.46
Affiliations    27.86
Description      0.00
Response        82.12
Victims          5.82
Sponsor          8.73
Type             7.07
Category         4.78
Sources_1        1.25
Sources_2       26.20
Sources_3       65.07
dtype: float64

Plotting NULL Values graph¶

In [10]:
mn.matrix(cyber, figsize=(25,10))
Out[10]:
<AxesSubplot:>
In [11]:
cyber_null = pd.DataFrame((cyber.isnull().sum())*100/cyber.shape[0]).reset_index()
cyber_null.columns = ['Column Name', 'Null Values Percentage']
fig = plt.figure(figsize=(10,5))
ax = sns.pointplot(x="Column Name",y="Null Values Percentage",data=cyber_null,color='blue')
plt.xticks(rotation =90,fontsize =7)
ax.axhline(50, ls='--',color='red')
plt.title("Percentage of NULL values in cyberattack data")
plt.ylabel("Null Values (%)")
plt.xlabel("Columns", )
plt.show()
In [12]:
fig,ax = plt.subplots(figsize=(20, 2))
cyber_null=cyber_null.set_index(cyber_null['Column Name'])
sns.heatmap(pd.DataFrame(cyber_null["Null Values Percentage"]).transpose(),cmap = 'coolwarm')
plt.show()

Insight

We can notice that Responses column has the most null values

Visualization¶

Category of Cyber Attacks¶

In [13]:
cyber_no_null_cat = cyber[cyber["Category"].notna()]
cyber_list = cyber_no_null_cat[(cyber_no_null_cat['Category'].str.contains(','))]
cyber_list = cyber_no_null_cat[(~cyber_no_null_cat['Category'].str.contains(','))]["Category"].unique().tolist()
cyber_category = []
cat_count = []
for i in cyber_list:
    cyber_category .append(i)
    cat_count.append(cyber_no_null_cat[cyber_no_null_cat.Category.str.contains(str(i))]["Category"].count())

cyber_new_cat = pd.DataFrame(cyber_category, columns =['Category'])
cyber_new_cat['Count'] = cat_count
cyber_new_cat = cyber_new_cat.sort_values('Count',ascending=False)
cyber_new_cat
Out[13]:
Category Count
0 Government 240
1 Private sector 232
3 Civil society 103
2 Military 60
In [14]:
fig = px.bar(cyber_new_cat, x='Category', y='Count', title='Cyberattack Category', color='Category',)
fig.update_traces(marker_line_color='black',marker_line_width=1, opacity=0.75, width=0.5)
fig.show()
In [15]:
fig = px.pie(cyber_new_cat, values='Count', names='Category', title='Cyberattacks Category', width=450, height=450)
fig.show()

Types of cyber attacks over time¶

In [16]:
cyber['Date'] = pd.to_datetime(cyber['Date'])
fig = px.line(cyber, x='Date', y='Type', title='Cyberattack types over time', color="Type",hover_name="Title")
fig.show()

Major sponsors of cyber attacks (country/origin)¶

In [17]:
cyber['Sponsor'] = cyber['Sponsor'].str.replace('of America','')
cyber_sponsor = cyber['Sponsor'].value_counts().reset_index()
cyber_sponsor.columns = ['Sponsor','Count']
cyber_sponsor

sponsor_no_null_cat = cyber[cyber["Sponsor"].notna()]
sponsor_list = sponsor_no_null_cat[(sponsor_no_null_cat['Sponsor'].str.contains(','))]
sponsor_list = sponsor_no_null_cat[(~sponsor_no_null_cat['Sponsor'].str.contains(','))]["Sponsor"].unique().tolist()

sponsor_new_list = []
sponsor_new_count = []
for i in sponsor_list:
    sponsor_new_list.append(i)
    sponsor_new_count.append(sponsor_no_null_cat[sponsor_no_null_cat.Sponsor.str.contains(str(i))]["Sponsor"].count())

sponsor_new_cat = pd.DataFrame(sponsor_new_list, columns =['Sponsor'])
sponsor_new_cat['Count'] = sponsor_new_count
sponsor_new_cat = sponsor_new_cat.sort_values('Count',ascending=False)
fig = px.pie(sponsor_new_cat.head(10), values='Count', names='Sponsor', title='Sponsor of Cyberattack')
fig.show()

Russia Sponsored Cyber Attack on Ukraine¶

In [18]:
russ_att_ukr = cyber[(cyber['Victims'].str.contains('Ukraine')) & (cyber['Sponsor'].str.contains('Russia')) & (cyber['Category'].str.contains('Government'))]
russ_att_ukr = russ_att_ukr.drop(['Sources_1','Sources_2','Sources_3','Response','Affiliations'],axis=1)
russ_att_ukr
Out[18]:
Title Date Description Victims Sponsor Type Category
182 Attempt to compromise Ukraine's judicial system 2018-12-04 Ukraine’s security agency thwarted an attack a... Ukraine Russian Federation Espionage Government
231 Compromise of Ukrainian government 2018-11-20 A Russian actor tied to Russia’s Federal Secur... Ukraine Russian Federation Espionage Government
252 Bad Rabbit 2017-10-24 Using a tool called Bad Rabbit, a threat actor... Ukraine, Japan, Russia, Bulgaria, Turkey Russian Federation Sabotage Government
259 NotPetya 2017-07-01 Threat actors deploy a tool, called NotPetya, ... Rosneft, WPP Plc., Maersk, Cie de Saint-Gobain... Russian Federation Data destruction Government, Private sector
331 Gamaredon 2015-04-28 A Russian-linked threat group known as Gamared... Ukraine Russian Federation Espionage Government
349 Targeting of Ukrainian law enforcement and gov... 2015-03-13 A threat actor attempted to compromise Ukraini... Ukraine Russian Federation Espionage Military, Government
361 Crouching Yeti 2014-07-31 This threat actor targets companies in the edu... United States, Spain, Japan, Germany, France, ... Russian Federation Espionage Private sector, Government
368 APT 28 2014-10-28 This threat actor is linked to espionage campa... Georgia, NATO, OSCE, France, Ukraine, United K... Russian Federation NaN Government, Military, Private sector
369 Sandworm 2014-11-03 This threat actor targets industrial control s... Russia, Ukraine, Poland, Lithuania, Belarus, A... Russian Federation Espionage Private sector, Government
374 Attempted compromise of Ukrainian email accounts 2014-12-09 A threat actor attempted to compromise email a... Ukraine Russian Federation Espionage Government, Military
399 The Dukes 2013-02-01 This threat actor targets government ministrie... United States, Georgia, Brazil, China, Japan, ... Russian Federation Espionage Government, Private sector
405 Red October 2013-01-14 This threat actor targets governments, diploma... Russia, Kazakhstan, Azerbaijan, Belgium, India... Russian Federation Espionage Government, Private sector
In [19]:
# Calculate the time range of cyberattacks by Russia on Ukraine
russ_att_ukr_days = russ_att_ukr['Date'].max() - russ_att_ukr['Date'].min()
# Convert the days to months and years
russ_att_ukr_days = russ_att_ukr_days / np.timedelta64(1, 'M')
print("Russia has been attacking Ukraine on the cyberfront for",round(russ_att_ukr_days) ,"months")
russ_att_ukr_days = russ_att_ukr['Date'].max() - russ_att_ukr['Date'].min()
russ_att_ukr_days = russ_att_ukr_days / np.timedelta64(1, 'Y')
print("That is close to",round(russ_att_ukr_days)

      ,"years")

Russia has been attacking Ukraine on the cyberfront for 71 months
That is close to 6 years

Web-Scraping for latest data¶

In [20]:
url = 'https://www.csis.org/programs/strategic-technologies-program/significant-cyber-incidents'
# Web scraping using BeautifulSoup
page = requests.get(url).text
soup = BeautifulSoup(page, 'lxml')
results = soup.find('div', class_="layout-detail-page__main")
news_list=[]
for i in results.find_all('p'):
    # Printing the text of the paragraph only if it contains the word 'Ukraine' and 'Russia'
    if 'Ukraine' in i.text and 'Russia' in i.text:
        new_list=i.text
        news_list.append(new_list)
        print(i.text,"\n")

# Converting into a dataframe
news_list_new = []
news_list_rest = []
for i in news_list:
    news_list_new.append(i.split(' ', 2)[0:2])
    news_list_rest.append(i.split(' ', 2)[2])
# Splitting date and description in different columns
news_list_new = pd.DataFrame(news_list_new, columns =['Date','Year'])
news_list_rest = pd.DataFrame(news_list_rest, columns =['Description'])
news_list_new = pd.concat([news_list_new, news_list_rest], axis=1)
news_list_new['Date'] = news_list_new['Date'] + ' ' + news_list_new['Year']
news_list_new = news_list_new.drop(['Year'],axis=1)
news_list_new['Date'] = news_list_new['Date'].str.replace('.','')

news_list_new

October 2022. Russian official, Vladimir Shin, accused the U.S. government and its
    allies of a coordinated campaign of cyberattacks against Russia. Shin cited
    comments from General Paul Nakasone confirming the U.S. "conducted a series
    of operations" in response to Russia's invasion of Ukraine.



October 2022.
    Hackers targeted Bulgarian websites belonging to the presidential
    administration, the Defense Ministry, the Interior Ministry, the Justice
    Ministry, and the Constitutional Court in a DDoS attack. A pro-Russian
    hacking group claimed responsibility for the attack, stating it was
    punishment “for betrayal to Russia and the supply of weapons to Ukraine.”


August 2022. Hackers targeted the website of Ukraine’s state energy agency responsible for the oversight of Ukraine’s nuclear power plants. The agency stated Russian hackers carried out the attack.

May 2022. Russian hackers hit Italian websites with a DDoS attack, including the Senate, the Ministry of Defence and the National Health Institute. The group states its goal was to target NATO countries and Ukraine.

April 2022.  The Romanian National Directorate of Cyber Security said that multiple public and private sector websites were hit with DDoS attacks. The victims included the ministry of defense, border police, national railway company, and the OTP Bank. A group claiming credit for the attack said on Telegram that it hacked the websites because Romania supported Ukraine since the Russian invasion of the country.

April 2022 . Hackers targeted a Ukrainian energy facility, but CERT-UA and private sector assistance largely thwarted attempts to shutdown electrical substations in Ukraine. Researchers believe the attack came from the same group with ties to the Russian GRU that targeted Ukraine’s power grid in 2016, using an updated form of the same malware.

February 2022. The websites of the Ukrainian Cabinet of Ministers and Ministries of Foreign Affairs, Infrastructure, and Education were disrupted in the days before Russian troops invaded Ukraine. Wiper malware was also used to penetrate the networks of one Ukrainian financial institution and two government contractors.
Out[20]:
Date Description
0 \nOctober 2022 Russian official, Vladimir Shin, accused the U...
1 \nOctober 2022\n Hackers targeted Bulgarian websites belongi...
2 August 2022 Hackers targeted the website of Ukraine’s stat...
3 May 2022 Russian hackers hit Italian websites with a DD...
4 April 2022 The Romanian National Directorate of Cyber Se...
5 April 2022 . Hackers targeted a Ukrainian energy facility...
6 February 2022 The websites of the Ukrainian Cabinet of Minis...

Applying NLP to fetch out keywords¶

In [21]:
# Getting key words from news_list_new Description column using nltk
from nltk.tokenize import word_tokenize
from nltk.corpus import stopwords
stop_words = set(stopwords.words('english'))

# Creating a list of words from the Description column
words = []
for i in news_list_new['Description']:
    words.append(word_tokenize(i))

# Removing the stop words from the list of words
words_new = []
for i in words:
    words_new.append([w for w in i if not w in stop_words])

# Removing the punctuations from the list of words
words_new_new = []
for i in words_new:
    words_new_new.append([w for w in i if w.isalpha()])

# Adding the words as new column to the dataframe
news_list_new['Key Words'] = words_new_new
news_list_new
Out[21]:
Date Description Key Words
0 \nOctober 2022 Russian official, Vladimir Shin, accused the U... [Russian, official, Vladimir, Shin, accused, g...
1 \nOctober 2022\n Hackers targeted Bulgarian websites belongi... [Hackers, targeted, Bulgarian, websites, belon...
2 August 2022 Hackers targeted the website of Ukraine’s stat... [Hackers, targeted, website, Ukraine, state, e...
3 May 2022 Russian hackers hit Italian websites with a DD... [Russian, hackers, hit, Italian, websites, DDo...
4 April 2022 The Romanian National Directorate of Cyber Se... [The, Romanian, National, Directorate, Cyber, ...
5 April 2022 . Hackers targeted a Ukrainian energy facility... [Hackers, targeted, Ukrainian, energy, facilit...
6 February 2022 The websites of the Ukrainian Cabinet of Minis... [The, websites, Ukrainian, Cabinet, Ministers,...

Conclusion

From the Analysis, Cyber Warfare is going to the new method of war rather than swords and guns and cannons. With the rise of digitalization, threat actors are finding more and more methods to exploit others. When this crosses national boundaries and onto bigger governmental/military target, it blows up into a cyberwar. There is urgent need to have top-tier cyber security across all levels - from the civillians to the highest power of the nation.

The End¶
